| Dimensioni metriche (mm) | Dimensioni imperiali (pollici) | Dimensioni del dash SAE | ID Min (mm) | ID Max (mm) | WD Min (mm) | WD Max (mm) | OD Tipo 2ST (mm) | OD 2SN Tipo (mm) | WP (Mpa) | WP (Psi) | PP (MPa) | PP (Psi) | Pressione sanguigna (MPa) | BP (Psi) | Raggio di curvatura minimo (mm) | Peso (kg/m) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 | 3/16 | -3 | 4.9 | 5.4 | 10.6 | 11.6 | 15.1 | 16.7 | 41,5 | 6020 | 83 | 12035 | 165 | 24080 | 90 | 0,32 |
| 6.3 | 1/4 | -4 | 6.4 | 7.0 | 12.1 | 13.3 | 16.7 | 18.3 | 40 | 5800 | 80 | 11600 | 160 | 23200 | 100 | 0,36 |
| 8 | 5/16 | -5 | 7.9 | 8.5 | 13.7 | 14.9 | 18.3 | 19.9 | 35 | 5075 | 70 | 10150 | 140 | 20300 | 115 | 0,45 |
| 10 | 3/8 | -6 | 9.5 | 10.1 | 16.1 | 17.3 | 20.6 | 22.2 | 33 | 4785 | 66 | 9570 | 132 | 19140 | 125 | 0,54 |
| 12.5 | 1/2 | -8 | 12.7 | 13.5 | 19.0 | 20.6 | 23.8 | 25.4 | 27,5 | 3990 | 55 | 7975 | 110 | 15950 | 180 | 0,68 |
| 16 | 5/8 | -10 | 15.8 | 16.7 | 22.2 | 23.8 | 27.0 | 28.6 | 25 | 3625 | 50 | 7250 | 100 | 14500 | 205 | 0,80 |
| 19 | 3/4 | -12 | 18.8 | 19.8 | 26.2 | 27.8 | 31.0 | 32.6 | 21.5 | 3120 | 43 | 6235 | 85 | 12325 | 240 | 0,94 |
| 25 | 1 | -16 | 25.4 | 26.4 | 34.1 | 35.7 | 38,5 | 40,9 | 16.5 | 2390 | 32,5 | 4710 | 65 | 9425 | 300 | 1.35 |
